0

ADD #data,A

Add to reg. A an immediate oper.

1

ADD #data,B

Add to reg. B an immediate oper.

2

ADD addr,A

Add to reg. A from a direct addr.

3

ADD addr,B

Add to reg. B from a direct addr.

4

ADD (addr),A

Add to reg. A from an indirect addr.

5

ADD (addr),B

Add to reg. B from an indirect addr.

6

ADD B,A

Add B reg. to contents of A reg.

7

ADD A,B

Add A reg. to contents of B reg.

8

ADD (B),A

Add B reg. indirect oper. to A reg.

9

ADD (A),B

Add A reg. indirect oper. to B reg.

A

ADD B+addr,A

Add to reg. A from an indexed addr. (index in B)

B

ADD A+addr,B

Add to reg. B from an indexed addr. (index in A)

10

ADC #data,A

Add with carry to reg. A an immediate oper.

11

ADC #data,B

Add with carry to reg. B an immediate oper.

12

ADC addr,A

Add with carry to reg. A from a direct addr.

13

ADC addr,B

Add with carry to reg. B from a direct addr.

14

ADC (addr),A

Add with carry to reg. A from an indirect addr.

15

ADC (addr),B

Add with carry to reg. B from an indirect addr.

16

ADC B,A

Add with carry to A reg. from B reg.

17

ADC A,B

Add with carry to B reg. from A reg.

18

ADC (B),A

Add with carry to B reg. a reg. indirect oper.

19

ADC (A),B

Add with carry to B reg. a reg. indirect oper.

1A

ADC B+addr,A

Add with carry to reg. A an indexed oper. (index in B)

1B

ADC A+addr,B

Add with carry to reg. B an indexed oper. (index in A)

20

SUB #data,A

Subtract an immediate oper. from A reg

21

SUB #data,B

Subtract an immediate oper. from B reg

22

SUB addr,A

Subtract from reg. A a direct oper.

23

SUB addr,B

Subtract from reg. B a direct oper.

24

SUB (addr),A

Subtract from reg. A an indirect oper.

25

SUB (addr),B

Subtract from reg. B an indirect oper.

26

SUB B,A

Subtract from reg. A the contents of reg. B

27

SUB A,B

Subtract from reg. B the contents of reg. A

28

SUB (B),A

Subtract from reg. A a reg. indirect oper.

29

SUB (A),B

Subtract from reg. B a reg. indirect oper.

2A

SUB B+addr,A

Subtract an indexed oper. from the reg. A (index in B)

2B

SUB A+addr,B

Subtract an indexed oper. from the reg. B (index in A)

32

SHL addr

Shift left a memory direct oper.

34

SHL (addr)

Shift left a memory indirect oper.

36

SHL A

Shift left reg. A

37

SHL B

Shift left reg. B

38

SHL (A)

Shift left a reg. indirect oper., addr. in A

39

SHL (B)

Shift left a reg. indirect oper., addr. in B

3A

SHL A+addr

Shift left an indexed oper. (index in A)

3B

SHL B+addr

Shift left an indexed oper. (index in B)

42

SHR addr

Shift right a direct oper.

44

SHR (addr)

Shift right a memory indirect oper.

46

SHR A

Shift right the contents of reg. A

47

SHR B

Shift right the contents of reg. B

48

SHR (A)

Shift right a reg. indirect oper.

49

SHR (B)

Shift right a reg. indirect oper.

4A

SHR A+addr

Shift right a memory indexed oper. (index in A)

4B

SHR B+addr

Shift right a memory indexed oper. (Index in B)

50

AND #data,A

AND operation on A reg and an immediate oper.

51

AND #data,B

AND operation on B reg and an immediate oper.

52

AND addr,A

AND operation on A and a direct oper.

53

AND addr,B

AND operation on B and a direct oper.

54

AND (addr),A

AND operation on A and an indirect oper.

55

AND (addr),B

AND operation on B and an indirect oper.

56

AND B,A

AND on A and B, result in A

57

AND A,B

AND on B and A, result in B

58

AND (B),A

AND on A and a reg. indirect oper.

59

AND (A),B

AND on B and a reg. indirect oper.

5A

AND B+addr,A

AND operation on A and an indexed oper.

5B

AND A+addr,B

AND operation on B and an indexed oper.

60

OR #data,A

OR operation on A reg and an immediate oper.

61

OR #data,B

OR operation on B reg and an immediate oper.

62

OR addr,A

OR operation on A and a direct oper.

63

OR addr,B

OR operation on B and a direct oper.

64

OR (addr),A

OR operation on A and an indirect oper.

65

OR (addr),B

OR operation on B and an indirect oper.

66

OR B,A

OR on A and B, result in A

67

OR A,B

OR on B and A, result in B

68

OR (B),A

OR on A and a reg. indirect oper.

69

OR (A),B

OR on B and a reg. indirect oper.

6A

OR B+addr,A

OR operation on A and an indexed oper.

6B

OR A+addr,B

OR operation on B and an indexed oper.

72

NOT addr

NOT operation on a direct oper.

74

NOT (addr)

NOT operation on an indirect oper.

76

NOT A

NOT operation on A reg.

77

NOT B

NOT operation on B reg.

78

NOT (A)

NOT on a reg. indirect oper. (address in A)

79

NOT (B)

NOT on a reg. indirect oper. (address in B)

7A

NOT A+addr

NOT on an indexed oper. (index in A)

7B

NOT B+addr

NOT on an indexed oper. (index in B)

7C

SWAP A

Swap A register lo and hi bytes

7D

SWAP B

Swap B register lo and hi bytes

80

CMP #data,A

Compare an immediate oper. with A reg

81

CMP #data,B

Compare an immediate oper. with B reg

82

CMP addr,A

Compare a direct oper. with A reg.

83

CMP addr,B

Compare a direct oper. with B reg.

84

CMP (addr),A

Compare an indirect oper. with A reg.

85

CMP (addr),B

Compare an indirect oper. with B reg.

86

CMP B,A

Compare A and B reg.

87

CMP A,B

Compare B and A reg.

88

CMP (B),A

Compare A with a reg. indirect oper.

89

CMP (A),B

Compare B with a reg. indirect oper.

8A

CMP B+addr,A

Compare with A an indexed oper.

8B

CMP A+addr,B

Compare with B an indexed oper.

8C

PUSH A

Push A onto the stack

8D

PUSH B

Push B onto the stack

8E

POP A

Pop A from the stack

8F

POP B

Pop B from the stack

90

MOVE #data,A

Move an immediate oper. into A

91

MOVE #data,B

Move an immediate oper. into B

92

MOVE addr,A

Load reg. A from a direct addr.

93

MOVE addr,B

Load reg. B from a direct addr.

94

MOVE (addr),A

Load reg. A from an indirect addr.

95

MOVE (addr),B

Load reg. B from an indirect addr.

96

MOVE B,A

Move B reg. to A reg.

97

MOVE A,B

Move A reg. to B reg.

98

MOVE (B),A

Load A reg. with a reg. indirect oper.

99

MOVE (A),B

Load B reg. with a reg. indirect oper.

9A

MOVE B+addr,A

Load A reg from an indexed addr. (index in B)

9B

MOVE A+addr,B

Load B reg from an indexed addr. (index in A)

A2

MOVE A,addr

Store the A reg. in memory at a direct addr.

A3

MOVE B,addr

Store the B reg. in memory at a direct addr.

A4

MOVE A,(addr)

Store reg. A at a mem. indirect addr.

A5

MOVE B,(addr)

Store reg. B at a mem. indirect addr.

A6

MOVE #data,SP

Move an immediate oper. into SP

A7

MOVE addr,SP

Load reg. SP from a direct addr.

A8

MOVE A,(B)

Store A reg. at an addr. held in B

A9

MOVE B,(A)

Store B reg. at an addr. held in A

AA

MOVE A,B+addr

Store A reg. at an indexed addr. (index in B)

AB

MOVE B,A+addr

Store B reg. at an indexed addr. (index in A)

AC

MOVE (addr),SP

Load reg. SP from an indirect addr.

AD

MOVE A,SP

Move A reg. to SP reg.

AE

MOVE B,SP

Move B reg. to SP reg.

B0

BCC #dis

Branch on carry clear to a PC relative addr.

B1

BCS #dis

Branch on carry set to a PC relative addr.

B2

BCC addr

Branch to a direct addr. if carry flag clear (C=0)

B3

BCS addr

Branch to a direct addr. if carry flag set (C=1)

B4

BCC (addr)

Branch to an indirect addr. if carry flag is clear

B5

BCS (addr)

Branch to an indirect addr. if carry flag is set

B8

BPL #dis

Branch on negative clear to a PC relative addr.

B9

BMI #dis

Branch on negative set to a PC relative addr.

BA

BPL addr

Branch to a direct addr. if negative flag clear (N=0)

BB

BMI addr

Branch to a direct addr. if negative flag set (N=1)

BC

BPL (addr)

Branch to an indirect addr. if negative flag is clear

BD

BMI (addr)

Branch to an indirect addr. if negative flag is set

C0

BNE #dis

Branch on zero clear to a PC relative addr.

C1

BEQ #dis

Branch on zero set to a PC relative addr.

C2

BNE addr

Branch to a direct addr. if zero flag clear (Z=0)

C3

BEQ addr

Branch to a direct addr. if zero flag set (Z=1)

C4

BNE (addr)

Branch to an indirect addr. if zero flag is clear

C5

BEQ (addr)

Branch to an indirect addr. if zero flag is set

C8

BVC #dis

Branch on no overflow to a PC relative addr.

C9

BVS #dis

Branch on overflow to a PC relative addr.

CA

BVC addr

Branch to a direct addr. if overflow flag clear (V=0)

CB

BVS addr

Branch to a direct addr. if overflow flag set (V=1)

CC

BVC (addr)

Branch to an indirect addr. if overflow flag is clear

CD

BVS (addr)

Branch to an indirect addr. if overflow flag is set

D0

JSR addr

Jump to subroutine at a direct address

D1

JSR (addr)

Jump to subroutine at an indirect address

D2

JSR A

Jump to subroutine at an addr. held in the A reg.

D3

JSR B

Jump to subroutine at an addr. held in the B reg.

D4

JSR (A)

Jump to subroutine at an indirect addr. held in the A reg.

D5

JSR (B)

Jump to subroutine at an indirect addr. held in the B reg.

D6

JSR A+addr

Jump to subroutine at an indexed addr. (index in A)

D7

JSR B+addr

Jump to subroutine at an indexed addr. (index in B)

D8

JSR #dis

Jump to subroutine at a PC relative address

E0

JMP addr

Jump to a direct addr.

E1

JMP (addr)

Jump to an indirect addr.

E2

JMP A

Jump to an addr. held in the A reg.

E3

JMP B

Jump to an addr. held in the B reg.

E4

JMP (A)

Jump to a reg. indirect addr.

E5

JMP (B)

Jump to a reg. indirect addr.

E6

JMP A+addr

Jump to an indexed addr. (index in A)

E7

JMP B+addr

Jump to an indexed addr. (index in B)

E8

JMP #dis

Jump to a PC relative address

F0

HALT

Halt processor

F1

RTS

Return from subroutine

F2

NOP

No operation

F3

INTE

Enable interrupts

F4

INTD

Disable interrupts

FA

TRAP #data

Software interrupt mechanism

FF

RTI

Return from interrupt
